This is a stock item. Order by 5pm Monday to Thursday and 4.30pm Friday for same day despatch.
If you have an account with us, you will be able to see stock levels and pricing for this product.
Specification
Sizes: 1/4" (DN8), 3/8" (DN10), 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1.1/4" (DN32), 1.1/2" (DN40) and 2" (DN50)
Connections: Female BSP Inlet x Female BSP Outlet
Materials: Gunmetal Body / Bonnet: Brass up to DN25 then from DN32 Cast Iron
Disk: Regulating Piston: Brass
Joints & Seals: Seals: NBR
Medium: Gases & Liquids i.e. Water (suitable for drinking water), neutral non-viscous fluids, compressed air, nitrogen, non-combustible gases. Not suitable for steam.
Inlet Pressure (Max): 40 Barg
Outlet Pressure Range: 1.5 to 20 Barg
Cv Range:
Temperature: 100 degC Max
Approvals: PED 97/23/CE category I
Notes: Highest Reduction Ratio: 6:1. We have a sizing calculator in the TECHNICAL INFO section on the menu bar above.
