This is a stock item. Order by 5pm Monday to Thursday and 4.30pm Friday for same day despatch.
If you have an account with us, you will be able to see stock levels and pricing for this product.
Specification
Sizes: 1/2" (DN15), 3/4" (DN20), 1" (DN25), 1.1/4" (DN32), 1.1/2" (DN40) and 2" (DN50)
Connections: Female BSP Inlet x Female BSP Outlet
Materials: Stainless Steel Body & Bonnet
Disk: Regulating Piston: Stainless Steel
Joints & Seals: Seals: FPM / FKM
Medium: Suitable for aggressive water and other aggressive liquids, compressed air, nitrogen and gases. Not suitable for steam.
Inlet Pressure (Max): 40 Barg
Outlet Pressure Range: 2 to 20 Barg
Kvs Range: 2.9 to 13
Temperature: 190 degC Max
Approvals: PED 97/23/CE category I
Notes: We have a sizing calculator in the TECHNICAL INFO section on the menu bar above.
